Signalpfeife, Trillerpfeife, Lockpfeife, Tonpfeife, Keramikpfeife, Spielzeugpfeife, Stimmpfeifen, Musikpfeifen, kleine Musikinstrumente und Zubehoer:Pfeifen, die nicht zum Rauchen sind, sondern, um Toene zu produzieren; Deutsche Signalinstrumentenfabriken, Deutschland. A. Strauss . ( Arbeit in Produktion)
Die Absicht dieses Artikels ist es, ein Bewusstsein fuer das oben genannte Thema zu schaffen Das Themenfeld der Sammlung von Trillerpfeifen ist nur wenig im oeffentlichen Interesse Deutschlands vertreten, oft nur als Nebenprodukt bekannt in der Ausruestung von Militaer, Polizei oder Feuerwehr. Dabei gibt es noch so viel mehr: im Transport wie im Zugverkehr, als Schmuck, im Sport, bei der Jagd, als Lockpfeife, Hundepfeife, als Spielzeug, als Geschenk oder Souvenir.
Das sind nur einige Beispiele. Bald mehr an dieser Stelle. Bei Interesse kontaktieren Sie mich gerne, wenn Sie selbst Trillerpfeifen und Zubehoer besitzen und mehr erfahren oder sich darueber austauschen moechten. Gerne koennen Sie mir Bilder senden. firstname.lastname@example.org
Continue reading Signalpfeife, Trillerpfeife, Lockpfeife, Tonpfeife, Keramikpfeife, Spielzeugpfeife, Stimmpfeifen, Musikpfeifen, kleine Musikinstrumente und Zubehoer. A. Strauss
Police Button Whistles from the Victorian area. A.Strauss
The next police whistles include the majority of known Police Button whistles which were found, some are not included either because of poor condition or since I did not keep Pictures of. Now as I start to carefully compare button whistle construction and button makers I am making progress in identifying makers, after years of research soon to be more.
Dewsbury Button police whistle
Continue reading Police Button Whistles, 19th Century Police Button Whistles. A. Strauss
Button Whistles I. Button Whistles Corner 1.
An English dog call or hunting signal call, Two different hand made copper buttons depicting a horse on one button and a dog on the other, I call these type art button whistles since the so called “Buttons” were never made as actual buttons but rather seem to be especially made as copper side plates.
The body is made of thick Iron, two parts, and a triangle made of thick wire for loop. Altogether 4 parts loop and pea. It is Victorian and an early Escargot type –
Snail Type – button whistle. The dating of these is not yet clear but an educated guess would be 1850s to 1870s.
Continue reading Button Whistles I. Button Whistles Corner. A.Strauss
This is the last part about James Dixon & Sons Whistles and History
in 9 parts. (See links to all 9 parts at bottom).
I started the article with Two Note Tube whistle (TNT) the one commonly identified with police whistles and invented by Porteous for Stevens & Sons,
It was only in 2006 that I discovered the first one.
There are two known examples of this whistle,
Here is a Drawing of model # 55 in Dixon’s catalogue of 1895. The whistle was made before that, and was described as a railway whistle.
Continue reading James Dixon & Sons Other Rare Whistles, Models & Designs. Part.II.c. Avner Strauss
Dixon & Sons Extractors & other combination whistles. A Strauss
A photo of 6 examples enlarged from the Sheffield City Collection;
Model #104R made late 1870s and later, Length; 75 mm Powder primer and picker combined with dog whistle.
Here is a drawing of this model #104N as appears in the 1882 catalogue
and in the Sheffield city collection.Model #220N from the same catalogue & period.
Model #220 as seen in the catalogue and actual one in closed position.
You may note that all this combination- shooting gudgets -multitools – with whistles, used round dog call whistles that were made as separate models before.Model #220N Powder primer with outside self-acting picker for gun nipples.
Model #220N as stamped on whistle was made late 1870’s early 1880s, shows in the 1882 catalogue.
Next; Moffatt’s Patent #11396 registered 1887. It included a spring blade which comes out between the two cartridge puller claws.
Continue reading Dixon & Sons Extractors – Cartridge Pullers, Shooting Gudgets with Dog Whistles, combination whistles & Other Dual Function Combination Whistles. II. b. A Strauss
Dixon & Sons Round Britannia Metal Whistles & Model #49.
James Dixon started making Britannia Metal (Invented c.1770) whistles Before 1850, Here is a group photo of 16 round pea britannia metal whistles,
11 of which were positively identified as made by Dixon & Sons, two were later found in a German (Marked as such).
Some marked X still need a second close examination dew to newly discovered catalogues by other makers.
Model #10 was made in two sizes, a distinctive Dixon’s Flushed Pillar Top Finial.
See the two sizes made in the group photo above top right is the larger model and 3rd from top left the smaller. This model was made in two sizes, but other earlier versions are noted;
Continue reading Dixon & Sons Round Britannia Metal Whistles & Model #49. Part I.e. A Strauss
James Dixon & Sons Round Brass & German Silver Round Whistles (Part I.d.)
After the First Early period 1800 to 1835 and later up to 1865 which was reviewed here with early examples I move forward to look at some more German Nickel or Nickel Silver & Brass whistles, not it in chronological order.
Cracking the general early date code of whistles in the article about Stevens & Sons was a Benchmark, which enabled a clearer view of another giant whistle maker – Dixon & Sons. At the top a whistle which had been made by James Dixon the founder himself. (See next Paragraph).
Continue reading James Dixon & Sons Round Brass & German Silver Round Whistles (Part I.d.) A. Strauss
19th Century Ivory Bone & Horn Whistles by James Dixon & Sons , Part I. b.
See Part I and sub parts.
Dixon started turning Ivory & wood whistles while still named Dixon & Son In the early 1820s, and may be earlier, Horn whistles were probably made at the same period but Pressed horn whistles were made later, probably around the late 40s. Model # 15, made in Horn as well, Model #5 (1883 Catalogue).
Dixon Octagonal whistle made in Ivory & Horn with typical Dixon top (Although Linegar used a similar top design) Here you can see another round Bone whistle
with the same top.
Model #6 Stag Horn, Catalogue mentions #6C ‘Stag Horn 2nd Quality’
and #6CC ‘common quality’
Next is a larger horn very old dog call with nice patina.
A later stag horn Model #6 variatin.
Left to right: 33.5mm First Period, / 53.5mm of top quality / Bone; 66.6mm /Ivory; 72mm (Probably model #7L) one of their most expensive whistles at the time.
More Ivory whistles, Left; 44mm right; Oval shaped 46mm similar to Model number #47 in N.P Brass Continue reading James Dixon & Sons, Part I. b. Round Ivory Bone & Horn Whistles. A.Strauss
PART I.a. Underconstruction
ROUND & ROUND PEA WHISTLES
This part starts with metal whistles (one wooden) excluding Britannia metal made whistles which are to be uploaded later, and continues with Ivory,
Horn & Stag horn made whistles. Materials & Identifying features for Dixon whistles would be discussed later. The Part dealing with round whistles terminating with an Animal Head can be viewed here, Part I here,The begining of Part II. a., Here.
Dew to the length PART I of the article was divided into 7 parts, all posted.
Dixon’s whistle’s timeline divided roughly to three periods over the 19th century;
Early – Pre 1835 Dixon, Dixon & Son
Middle – 1835 Dixon & Sons
Later 19th Century c. 1865 – 1900
The earliest whistles Dixon made were round whistles.
These were very sturdy cast or machined from one metal rod with no hole at top, the drilled hole came later, I believe the early ones were made mostly for military use. and later quality was upgraded in terms of materials and designs for the elite, sportsmen, and later for railways.
A very early type: A special knot was used to tie a lanyard to the whistle’s top;
This whistle uses the “Sheffield Fipple” (a term I coined here) which is discussed in details, in a later paragraph here, and the round metal band below mouthpiece which may well be unique to Dixon (to be verified).
The next photo shows another very early Dixon on the left with the same features but a different top design, mushroom like.
A very early type beside the ‘next generation’
Continue reading James Dixon & Sons Part I. a. Round Whistles. A.Strauss
Dixon & Sons History and whistles in the 19th Century.*
PART II. a. ( See Part I and Part I.a.)
Dixon & Sons Conical Whistles, Beaufort type Whistles.**
It should be noted that all conical whistles which many call Beaufort type, were classified as RAILWAY whistles in the 19th century Dixon catalogues.
TWO WINDOWS FLAT DIAPHRAGM MODELS
Model # 43 & #43S Railway whistles with Ivory Mouthpiece were made for MANY years. These are listed in the 1883 price list. We should try to date the earlier ones.
Continue reading James Dixon & Sons Conical Whistles Part II.a. By Avner Strauss
